Переходник короткий тип -AG-дюйм./IG-дюйм.
| Код | Резьба | СН | L | L1 | L2 | Давление PN | |
| F1 | F2 | мм | мм | мм | мм | бар | |
| ARMFC0402 | 1/4 '' | 1/8 '' | 19 | 18 | 11 | 300 | |
| ARMFC0602 | 3/8 '' | 1/8 '' | 22 | 21,5 | 12,5 | 280 | |
| ARMFC0604 | 3/8 '' | 1/4 '' | 22 | 21,5 | 12,5 | 280 | |
| ARMFC0802 | 1/2 '' | 1/8 '' | 27 | 24 | 14 | 200 | |
| ARMFC0804 | 1/2 '' | 1/4 '' | 27 | 24 | 14 | 200 | |
| ARMFC0806 | 1/2 '' | 3/8 '' | 27 | 24 | 14 | 200 | |
| ARMFC1204 | 3/4 '' | 1/4 '' | 32 | 27 | 16 | 200 | |
| ARMFC1206 | 3/4 '' | 3/8 '' | 32 | 27 | 16 | 200 | |
| ARMFC1208 | 3/4 '' | 1/2 '' | 32 | 27 | 16 | 200 | |
| ARMFC1604 | 1 '' | 1/4 '' | 41 | 32 | 18 | 120 | |
| ARMFC1606 | 1 '' | 3/8 '' | 41 | 32,5 | 18 | 120 | |
| ARMFC1608 | 1 '' | 1/2 '' | 41 | 31,5 | 18 | 120 | |
| ARMFC1612 | 1 '' | 3/4 '' | 41 | 32 | 18 | 120 | |
| ARMFC2008 | 1.1/4'' | 1/2'' | 50 | 34 | 21 | 105 | |
| ARMFC2012 | 1.1/14'' | 3/4'' | 50 | 34 | 21 | 105 | |
| ARMFC2016 | 1.1/4'' | 1'' | 50 | 35,5 | 21 | 105 | |
| ARMFC2408 | 1.1/2'' | 1/2'' | 55 | 36 | 21 | 105 | |
| ARMFC2412 | 1.1/2'' | 3/4'' | 55 | 36 | 21 | 105 | |
| ARMFC2416 | 1.1/2'' | 1'' | 55 | 36 | 21 | 105 | |
| ARMFC2420 | 1.1/2'' | 1.1/4'' | 55 | 36 | 21 | 105 | |
| ARMFC3216 | 2'' | 1'' | 70 | 42,5 | 25 | 70 | |
| ARMFC3220 | 2'' | 1.1/4'' | 70 | 42,5 | 25 | 70 | |
| ARMFC3224 | 2'' | 1.1/2'' | 70 | 42,5 | 25 | 70 | |
| ARMFCM0612 | 3/8 '' | 12x1.5 | 22 | 21,5 | 12,5 | 9 | 280 |
| ARMFCM0614 | 3/8 '' | 14x1.5 | 22 | 21,5 | 12,5 | 9 | 280 |
| ARMFCM0812 | 1/2 '' | 12x1.5 | 27 | 24 | 14 | 10 | 200 |
| ARMFCM0814 | 1/2 '' | 14x1.5 | 27 | 23 | 14 | 9 | 200 |
