Полуфланцевое парное соединение – скоба SAE 6000 PSI

Код DN Inches ø Резьба A B C D E F I
    "    F
SFP08 12 1/2" 8 1/2" 56 23.6 40.5 8.75 09.1 22 16
SFP12 20 3/4" 12 3/4" 71 30 50.8 10.8 11.9 28 19
SFP16 25 1" 16 1" 81 35 57.1 13 13.9 32 24
SFP20 32 1.1/4" 20 1.1/4" 95 38.6 66.7 15 15.8 38 27
SFP24 40 1.1/2" 24 1.1/2" 113 47.5 79.4 17 18.3 42 30
SFP32 50 2" 32 2" 134 57 96.8 21 22.2 52 37
